VSX-531 (B)

5.1-Channel AV Receiver with Built-in Bluetooth®

Ultra HD (4K/60p/4:4:4) pass-through with HDCP 2.2
Advanced Sound Retriever
Built-in Bluetooth^®
140 W/ch (6 ohms, 1 kHz, THD 1.0 %, 1ch Driven)
80 W/ch (8 ohms, 20 Hz-20 kHz, THD 0.08 %, 2ch Driven FTC)

PRICE :

Rs. 41900 Rs. 39900

YOUR ENTRY TO ENHANCED AUDIO FIDELITY

The Pioneer VSX-531 AV receiver is the ideal centerpiece for elevating your home theater system to a richer, more authentic audio experience. As a starting gateway into the immersive world of High Definition surround sound, the VSX-531 features 4 HDMI inputs and Ultra HD (4K/60p/4:4:4) pass-through with HDCP 2.2, easily handling the latest technology and devices, with standard support for all of the latest HDR video standards for vivid high-resolution playback.

Enhance your listening experience with audio streaming from your mobile devices using the built-in Bluetooth^® Wireless Technology, or with Pioneer’s signature Phase Control technology for synchronized sound, delivering a realistic and dynamic performance made for your room.

CONTROL THE POWER OF SOUND

Pioneer designed the VSX-531 AV receiver to deliver powerful cutting edge features at an entry-level price point. The VSX-531 is equipped with a 5 channel discrete amplifier with the same quality on all 5.1-channels delivering up to 140 Watts (6 ohms, 1 kHz, THD 1.0 %, 1ch Driven) of power per channel of clear audio reproduction.

EMBELLISH LOW-FREQUENCY AMBIENCE

The VSX-531 creates a dynamic, lively, and realistic ambience derived from the original sources, expressing the audio details as the artist intended. Most typical AV receivers use a Low Pass Filter to process low-frequency signals for the subwoofer when amplifying multi-channel audio signals causing low frequency “phase lag” from the main channels. The Pioneer Phase Control technology effectively eliminates phase lag, enriching the booming power of deep, low frequency audio, while maintaining the original’s subtle nuances.

4K UltraHD COMPATIBLE

The VSX-531 supports 4K/60p/4:4:4 24-bit video signal transmission using HDCP 2.2 technology, ensuring you always have access to the many upcoming 4K UltraHD sources and televisions with HDR. Ready for the next upgrade to your visual experience, Pioneer engineered the VSX-531 receiver to be compatible with the latest standards.

HD AUDIO UNCOMPRESSED

Expand your audio library with the ultimate in sound reproduction using high-definition audio formats with Dolby^® TrueHD^® and DTS-HD^® to deliver Blu-ray Disc soundtracks with unsurpassed audio quality. The VSX-531 also supports Dolby and DTS surround formats, the best formats for the wide variety of available entertainment sources.

ADVANCED SOUND, ENHANCED DETAIL

The VSX-531 incorporates Pioneer’s Advanced Sound Retriever (ASR) to improve the dynamic response from compressed music sources and restore the subtle details left out during the compression process. Ideal for use with WMA, AAC and MP3 files played via disc or USB, ASR makes music sound more realistic than before for enhanced playback that sounds as close to the original recording.

BLUETOOTH® BUILT-IN

Easily enjoy music from other devices with the built-in Bluetooth Wireless Technology, the most convenient wireless streaming solution. Pair the VSX-531 with compatible devices and wirelessly listen to all of your favorite streaming music services as well as your own music library, for access to your favorite music genres!

CONNECTED AND READY

Plug a thumb drive into the standard front panel USB port and instantly playback all your favorite MP3, WMA and AAC music files. With four HDMI, additional optical and coaxial digital inputs, the VSX-531 delivers a wide range of audio, composite video connections for all your devices as well as a headphone jack for the ultimate private listening experience.

SMART POWER

Go Green with the intelligent ECO Mode that automatically analyzes your sources in real-time and adjusts power consumption or manually select power-saving settings for the best listening experience.

SPECS

POWER
Amplifier Design Discrete Direct Energy	Channels 5.1
Power Output: Watts per Channel (20Hz-20kHz,.08%THD@8ohm 2ch Driven) 80 Watts	Power Output: Watts per Channel (1kHz,1%THD@6ohm 1ch Driven) 140 Watts
Estimated Power Consumption/Network Standby off 210 W/45 W

HANDHELD AND INTERNET
AirPlay —	HTC Connect —
Made for iPhone and iPod —	iOS/Android Remote Control APP —
TIDAL Music Streaming Service Ready —	Streaming Audio From PC/Network Yes
Internet Radio —	Pandora Internet Radio —

DECODERS & FORMATS
Digital Core DSP Engine Digital Core Engine with Texas Instruments Aureus DSP	Audio DACs 192K/24Bit
Audio Processing —	iPod Digital Audio —
Music File Playback 48kHz / 16-Bit MP3, WMA, ACC Via USB	High-Definition Copy Protection (HDCP) 2.2
Dolby Atmos —	Dolby TrueHD Yes
Dolby Digital Plus Yes	DTS:X Yes
DTS-HD Master Audio Yes	DTS Neural:X —
DTS Neo:X —	HDMI SACD Transfer 2 Channel

SOUNDFIELD CALIBRATION
Phase Control Yes	MCACC —
MCACC Memory —	Standing Wave Control —
EQ Bands —	Symmetric EQ —
X-Curve —	Distance Adjustment 0.1 feet
Polarity Check —	Auto Subwoofer Crossover —

LISTENING MODES
Auto Surround Yes	Stream Direct Yes (Direct, Pure Direct)
Advanced Surround 10+1	Wide Surround —
Front Stage Surround Advance —	Headphone Surround —
Virtual Speakers —

AUDIO FEATURES
Dialog Enhancement —	Advanced Sound Retriever Yes
DSD Music File —	Sound Retriever AIR —
Digital Noise Reduction —	Tone Control 2 Channel
Sound Delay (Lip Sync) Yes (500ms)	Speaker A/B —
Bi-Amp —

VIDEO PROCESSING
4K Ultra HD Pass-Through Yes	4K Ultra HD Video Scaler —
3-D Ready Yes	Audio Return Channel Yes
HDMI Standby Through Yes with Input Switch / Last Memory	HDMI 36-bit Deep Color Yes
HDMI x.v. Color Yes	Video Processor —
Video Converter to HDMI —	HDMI to HDMI Video Scaler 4
Component Video Scaler —	Composite Video Scaler —
Pure Cinema I/P Converter —	Advanced Video Adjustment —
3D Noise Reduction —	Super Resolution —

CONNECTIVITY
HDMI Input / Output 4 In (Rear) / 1 Out	MHL 2 —
Wi-Fi Built-In 1	Bluetooth Built-In Yes
Wireless Adapter Port —	Bluetooth Adapter Port —
Component Video Input / Output —	Composite A/V Input / Output 2 In (Coaxial x 1, Optical x 1)
iPhone / iPod / USB Memory Input —	USB Terminal Front USB
Ethernet Input —	Analog Audio Inputs / Output 3 in
Digital Audio Inputs / Output 2 In	Pre-Amp Output 1 ch (SW).
Headphone Output Yes	Front A/V Inputs USB (Audio Only)
AM/FM Presets 30

INSTALLATION
On-Screen Display HDMI Only	Auto Power Down Yes
Multi-Room and Source Output —	IR Serial Remote In/Out —
Multi-Zone On-Screen Display —	FL Dimmer Yes
Function Rename —	Remote Yes
Sleep Timer Yes

CONSTRUCTION
Front Panel Brushed	Speaker Terminals 2 large + 3 clip

WARRANTY
Warranty 1 Year Parts & Labor

DIMENSIONS
W x H x D (inches) Wi-Fi Antenna’s Up —	W x H x D (inches) 17.1 x 6.6 x 12.6
Weight 17.6 lbs

MANUALS

Quick Start Guide

Product Sheet

Instruction Manual (English)
